Glass Flake Coating

Glass Flake Coatings are suitable for pipeline internal and tank internal coatings as well as for pump / rotatory equipment’s refurbishment. These offer solutions to replaced exotic metals such as Hast alloy / S.S 316 L etc. with Coated M.S. vessels / equipment’s, resulting in excellent service life and most importantly savings for the user.
The key Features of these products as under:

Impermeability : Multitude of overlapping layers of screened Glass Flake particles in parallel orientation form a highly impermeable surface, a minimum of 500-700 microns DFT.

Corrosion : The coating provides a solid barrier against the attack of corrosive ions over a pH range of    1 to 14.

Abrasion : With a minimum barcol hardness of 42 and a thermal coefficient of expansion similar to that of the substrate, the coating with stands mechanical without any undercutting.

Erosion : The coatings have excellent resistance to erosion, hence extending service life substantially.

Adhesion : Superior adhesion is achieved by the surface tension effect of our Coating Systems and screened particles of Glass Flake.The coating does not generally delaminate, peel or blister if the metal flexes within its elastic limits...

Electrolysis : Galvanic corrosion is minimized by the superior dielectric strength of these coating.

Machining : Rotary components of Pumps, valves and impellers, etc., can be machined with conventional metal tools.

Repair : In case of accidental damage / touch up requirements, the existing coating can be easily repaired at site and the recoating forms part of the original coating.



Industry Applications


Marine :  Hulls, Decks, Rudders, Thruster Tunnels

Nuclear & Power Generation : Scrubbers, Condenser Water Boxes, Water Pipes. Tanks.

Chemical : Acid/Caustic Tanks, Vessels, Floors, Neutralization Tanks

Oil Gas & Petro - Chemical : Separators, Tanks, And Splash Zones.

Food & Agriculture : Storage Tanks, Effluent Tanks, Juice, Wine and Beer Tanks, Sugar processing Milk Parlors, Floors, Pharmaceutical.

Water & Sewage : Potable water Tanks, Clarification Tanks, Pipes, and Desalination Plants.

Transport : Railway Carriages, Tankers.



Details of Some Prestigious Project that We Carried Out

S.No.ClientWork Details
1Nuclear power Corporation India Limited , TarapurDome Insulation of reactor with spray foam area 4000m2
2IDMC LTD, Gujarat100kl and 150KL silos Insulation
3Orchid Pharmaceuticals, madrasPipe Line Insulation
4Nectar Life Science , ChandīgarhPipe Line and tank Insulation
5Carbon Dioxide Mumbai and IDMC LTDMobile tank Insulation
6Mangalore ship AssociationShip Insulation
7Airtech System, VadodaraPanel Insulation
8BGR ENRGY LTDDome Insulation of reactor with spray foam area 4300m2
9KDMC60kl and 100KL silos Insulation



Elastomeric PU (Polyurea and polyurethane) coating

1Asset owner :- Indian oil, EPC contractor: - Lanco Infratech , Contractor - Samshi Pipe industries, BarodaInternal pipeline coating with Elastomeric PU area-1530 m2
2Orbit Group, MumbaiFloor coating with elastomeric polyuria area -8000m2
3GMW LTD, VadodaraElastomeric PU coating on log gate area 500m2
4GMW LTD, ChennaiElastomeric PU coating on log gate area -1600m2
5GMR LTDElastomeric Polyurea Coating in DM Plant Storage tank area 3500m2
6Prabha Steel IndustriesBullet Tank Coating 2no.
7BARC, TarapurConcrete Tank Coating 500m2
about us

J.S.PUF SYSTEM & SERVICES is promoted by a polymer technologist, specializing in Polyurethane Foams and PU coatings, with over of 15 years of experience.

From the company's early supplies of insulation products to the Indian Antarctica expedition in 2005 its strength has been reflected in the customized solutions spanning the auto industry, cold storage and fishing industry, chemical & process industries, building and industrial insulation requirements, pharms, healthcare,etc.
